# X11 Forwarding using an SSH Reverse Tunnel
X11 Forwarding is very useful when you want to run GUI based applications on a remote machine. I needed it to run IntelliJ IDE on HPC. But while X11 forwarding can be easily enabled using the -X (or -Y) option of ssh, it doesn't work if xauth is not installed on the remote server - in my case the HPC compute nodes. In this case, ssh can be used to create a reverse tunnel from the remote server to the local machine. X11Forwarding can then be done by setting the display on the remote server as the entry port of the tunnel and making the X-server listen on the exit port of the tunnel in the local machine.
Here I'll describe how I went about creating a SSH reverse tunnel from HPC compute nodes to my local machine and used that to enable X11 Forwarding. As a prerequisite, I assume that a Display Manager that launches the X-server is installed on the local machine. Popular ones are XQuartz for macOS and XMing for Windows.
1. Enable X11 forwarding on local machine.
1. Add this to /private/etc/ssh/sshd_config:
